High speed digital video cameras for slow motion analysis


image description
often used frame rates 500 to 2,000
image description
max resolution at fps 1280 x 1024 @ 500 fps
image description
max fps 100,000

The S-MOTION & S-PRI are entry level portable high speed cameras with high resolutions and good light sensitivity. The S-PRI is low priced with limited features, but highly customizable and additional “modules” can be added at any time. The S-MOTION offers a complete package.

  • Sample Record Rates: 1280 x 1024 @ 500 fps; 900 x 700 @ 1,000; 512 x 512 @ 2,110
  • Max Record Duration: Time typically measured in Seconds. Frame rate and resolution dependent.
  • Light Sensitivity: ISO 3,200 (Mono) Using Ssat 12232 (D) standard
  • Warranty: 1 Year
  • Minimum Shutter: 2 μs (microsecond)
  • Special Features: Battery, Customizable
  • Dynamic Range: 10 bit
  • Budgetary Range: See "Camera Guideline" button in top right of this page
Sensor Options: Color or Mono
Onboard Memory Options: 1.3GB, 2.6GB, 5.2GB, or 10.4GB (for actual record time, see “Spec Sheet” Link)
Models: Part of the AOS S Series (Other models include S-MIZE,S-MIZE EM, S-MIZE HD). See Camera Guideline for comparison of models.
Other Options Include: CF Storage, IRIG, Extended Battery Back (3+ hours), Video Out
